FV2 Floating Side Entry Ball Valve

The FV2 Floating Side Entry Ball Valve is manufactured from high-quality forged steel and designed in compliance with ISO 17292 standards. Available in 2-piece or 3-piece split body configurations, this valve is ideal for medium to high pressure applications and supports a wide operating temperature range from -196°C to 500°C.

As a cost-effective alternative to small-size trunnion mounted ball valves, the FV2 series is widely used in demanding industrial environments. All BLTV FV2 forged steel floating ball valves are fire-safe tested and certified by ECM’s Register in accordance with API 607 standards.

Size Range: 1/2”–10”
Pressure Class: ANSI 150–2500

Main Features and Options

• Body Design: Two- or three-piece split body construction with bolted joints

• Material Options: Wide range of materials for both body and internals, including:

  • Carbon steel

  • Low alloy steels

  • Stainless steels

  • Duplex 22/25 Cr

  • Nickel alloys

  • Titanium

• Surface Enhancements:

  • Overlays: Alloy 625 / 316L

  • Coatings: Tungsten Carbide, Chromium Carbide, ENP

• Seat Options: Available in soft or metal-seated designs

• Severe Service Capability:

  • Engineered for extreme service conditions, including high and low temperatures (cryogenic), erosive, abrasive, and corrosive environments

  • Metal-seated versions built for very severe applications

• Design Features:

  • Bidirectional flow design available

  • Overlay applied to dynamic sealing areas

  • Cladding in seat pocket areas

  • Fully internally clad for maximum protection

  • Tailored configurations for HIPPS (High Integrity Pressure Protection Systems) and ESD (Emergency Shutdown) applications
